Hdpe pipes

Category:

Products

HDPE Pipes

Hotline：

86-15705856568

Product Inquiry

POLYFUSION is a manufacturer of polyethylene pipes for water and gas supply. They are used in underground laying and installation of external engineering networks that meet the requirements for reliability and safety.

We sell proven products for the transport of cold potable and hot water, combustible natural/liquefied gases and media to which polyethylene is resistant. The pipes are made in China by extrusion from HDPE grades PE 100, are easily connected by welding and are designed for long service life due to their strength characteristics.

The main advantage:

*Resists abrasive wear and corrosion caused by external chemical or physicochemical influences.

*Thermal stability, resistance of materials and welded joints to constant internal pressure.

*Low internal surface roughness and maintain initial throughput throughout service life.

The pipeline has ISO certificate and complies with hygienic requirements. Simple and easy to install, they provide trouble-free gas and water supply during new system construction and existing system retrofits.

The catalog contains products for industrial and municipal installations with SDRs from 26 to 11, small or large outside diameters and wall thicknesses. This series allows you to purchase HDPE pipes according to their operating characteristics, conveying medium and working pressure.

Wholesale of PE pipes from the manufacturer：

We produce polyethylene pipes and ship them in bulk directly from the factory. This allows customers to buy items cheaper than at the store.

As a manufacturer and supplier, we are all about facilitating cooperation. We have stock and can ship quickly. You can specify a price for pipe of a specific size and application, or use the feedback form or call 0086-532-66733884 for a complete price list.

PE100 HDPE PIPES
Diameter (mm)	PN6/SDR26	PN8/SDR21	PN10/SDR17	PN12.5/SDR13.6	PN16/SDR11
Diameter (mm)	Thickness（mm)	Thickness（mm)	Thickness（mm)	Thickness（mm)	Thickness（mm)
20					2.3
25				2.3	2.3
32			2.3	2.4	3.0
40		2.3	2.4	3.0	3.7
50	2.3	2.4	3.0	3.7	4.6
63	2.5	3.0	3.7	4.7	5.8
75	2.9	3.6	4.5	5.6	6.8
90	3.5	4.3	5.4	6.7	8.2
110	4.2	5.3	6.6	8.1	10.0
125	4.8	6.0	7.4	9.2	11.4
140	5.4	6.7	8.3	10.3	12.7
160	6.2	7.7	9.5	11.8	14.6
180	6.9	8.6	10.7	13.3	16.4
200	7.7	9.6	11.9	14.7	18.2
225	8.6	10.8	13.4	16.6	20.5
250	9.6	11.9	14.8	18.4	22.7
280	10.7	13.4	16.6	20.6	25.4
315	12.1	15.0	18.7	23.2	28.6
355	13.6	16.9	21.1	26.1	32.2
400	15.3	19.1	23.7	29.4	36.3
450	17.2	21.5	26.7	33.1	40.9
500	19.1	23.9	29.7	36.8	45.4
560	21.4	26.7	33.2	41.2	50.8
630	24.1	30.0	37.4	46.3	57.2
710	27.2	33.9	42.1	52.2	64.5
800	30.6	38.1	47.4	58.8	72.6
900	34.4	42.9	53.3	66.2	81.7
1000	38.2	47.7	59.3	72.5	90.2
1200	45.9	57.2	70.6	88.2
1400	53.5	66.7	82.4	102.9
1600	61.2	76.2	94.1	117.6
1800	69.1	85.7	105.9
2000	76.9	95.2	117.6
2250	86.0	107.2
2500	95.6	119.1

Quality Assurance

We have the certificate of ISO9001 and CE,BV,SGS and CNAS approval with the strength of service, good quality and pretty competitive price. Customers’ biggest benefit is our goal, machine’s quality is the life of our company. By many years of growth, we have our best partners in the world.
